TK 540
Highly reliable and robust rim - engineered for daily commutes or the next around-the-world bike trip.
- MSRP US$ from $ 104
- Net weight from 545 g
- from € 75
- from CHF 83
Product details
The perfect rim for trekking or touring use, the TK 540 is ideal for those looking for the ultimate single welded strong aluminum rim. With double eyelets, the rim is plenty strong for touring the country side or commuting use. Available in 32 or 36 hole.
- Material ALUMINIUM
Model finder
Just a few clicks to find your model. Please use the filter below.
Zoom image
TK 540 29 18.2 mm DB VI
RCTK54DPD32S020171- Net weight 545 g
- recommended System weight max. 130 kg
- ASTM classification 2
- Material ALUMINIUM
- Rim joint Welded
- Tire interface Hooked / Crotchet tube type
- Brake Interface Disc
- Rim Diameter 29" / 700C
- Reference diameter ERD 600 mm
- Inner Width 18.2 mm
- Outer width 23.6 mm
- Rim Height 20.2 mm
-
Cross-section
- Number of holes 32
- Spoke bore rim Silver eyelet
- Valve hole Presta
- Inclusive -
Zoom image
TK 540 29 18.2 mm RB VI
RCTK54RPD32S020168- Net weight 545 g
- recommended System weight max. 130 kg
- ASTM classification 2
- Material ALUMINIUM
- Rim joint Welded
- Tire interface Hooked / Crotchet tube type
- Brake Interface Non disc
- Rim Diameter 29" / 700C
- Reference diameter ERD 600 mm
- Inner Width 18.2 mm
- Outer width 23.6 mm
- Rim Height 20.2 mm
-
Cross-section
- Number of holes 32
- Spoke bore rim Silver eyelet
- Valve hole Presta
- Inclusive -
Zoom image
TK 540 29 18.2 mm RB VI
RCTK54RPD36S020170- Net weight 545 g
- recommended System weight max. 130 kg
- ASTM classification 2
- Material ALUMINIUM
- Rim joint Welded
- Tire interface Hooked / Crotchet tube type
- Brake Interface Non disc
- Rim Diameter 29" / 700C
- Reference diameter ERD 600 mm
- Inner Width 18.2 mm
- Outer width 23.6 mm
- Rim Height 20.2 mm
-
Cross-section
- Number of holes 36
- Spoke bore rim Silver eyelet
- Valve hole Presta
- Inclusive -
-
Looking for conversion options, spare parts, manuals or how-to videos? Visit our product support.
-
Find help and answers for frequently asked questions here.
According to your selection TK 540 we found 3 models. Please use the model finder above to narrow down the models.
Select the model for which you need product support.
Find help and answers for frequently asked questions here.
-
DT Swiss sells its products exclusively via official dealers, some of which also have online shops. Please contact your dealer. Or contact the distributor for your country – please use the contact form and select your country first, followed by "Product availability" as the subject.
-
Compare the products on our website, where you can find our entire range and all technical specifications. Use the Wheel Finder to find the right wheel in just a few clicks.
Alternatively, contact a dealer – they know all about DT Swiss products and technologies and can advise you.
-
In cycling, rim height significantly impacts the aerodynamics, maneuverability and weight of the wheel. Basically, the higher the rim, the greater the aerodynamic advantage. The lower the rim, the more agile and maneuverable the handling.
-
Caution when choosing brake pads for wheels with rim brakes!
- Only "SwissStop Black Prince" brake pads may be used on carbon rims.
- Only "SwissStop BXP Blue" brake pads may be used on OXIC rims.
The use of incorrect brake pads can cause the rim to fail. DT Swiss takes no responsibility in this case. Please also note that brake pads which were previously used on aluminum rims must not be used on carbon rims. The aluminum abrasion in the brake pad can destroy the carbon. For further information about your wheel, please refer to the user manual.
If you notice these damage patterns on your wheel, contact a service center.
-
Tires with different widths and profiles are used depending on the surface. There are different recommendations for inner rim width depending on the choice of tire width for the respective road cycling purpose.
